Detail EasyBalance WIZARD, Windows-based Multi-plane Dynamic Balancing Calculator
EasyBalance WIZARD, Windows-based multi-plane dynamic balancing calculator
This software can transform any single-channel vibration instrument ( capable of measuring vibration and phase) into a full-featured, dynamic two-plane balancing system, with features previously only available with top-of-the-line balancing instrumentation.
The screens are self-explanatory and intuitive. Please feel free to explore the possibilities and features of this software. We always appreciate customer feedback. Customer feedback is what makes our products better. This software is the stand-alone version of our very successful EASYBALANCE software as designed for our dynamic balancing machines.
- WINDOWSï ¿ ½ point-and-click simplicity
- Single Plane or Two Plane
- Hard-bearing or Soft-bearing mode
- All possible rotor configurations are pre-programmed
- Drill depth program
- Component split program
- " Tape length " program for use with lead- or other weighted tapes
- Static / Couple separation program
- Print function
- Automatic log function
- Automatic weight calculations
- English / Metric selection
- Polar Graphic display
- Virtually unlimited rotor memory
- Graphical Influence Coefficient Program
Rotor setup screen
Graphical point-and-click user interface
6 pre-programmed balancing situations
Tooling compensation program
Rotor setup memory ( virtually unlimited rotor storage)
Convenient a, b, c dimensions
mm, inch, gram, ounce
Unbalance tolerance, for each plane
Data entry screen
Data entry screen simplifies data collection
1st run, no trial weights
Run with trial weight left
Run with trial weight right
Enter trial weight ( gram or ounces)
Enter trial weight angle
Enter trial weight radius
Polar graphic diagram
Polar Graphic diagram shows unbalance in a polar diagram
Color-coded dots show tolerance condition
" History dots " show the balancing progress
Switch Add or Remove on the fly
Convenient " Recalc " function ( no need to enter new data)
Static / couple separation
Static / couple separation program calculates static and couple components.
Static plane ( third plane) can be set to either left, center, or right.
Split-vector program
Split-vector screen allows " one click " calculation of weight distribution for segmented rotors
Choose between 3 to 99 segments.
